Excellent primary stability
Surface-treated threads ASTM F136 ELI Grade 5
i-Fix Compressive implant
C Series
Also known as i-Fix C-1. A one-piece compressive implant system designed for bone condensation with a reduced osteotomy workflow and a full range of narrow-to-wide diameters.
Ø 3.5–5.5 mmImplant body diameter
8–20 mmImplant lengths
27Catalog article codes
Catalog specification: a one-piece compressive body in ASTM F136 ELI Grade 5 titanium with surface-treated threads, listed from 3.5 to 5.5 mm diameter in lengths from 8 to 20 mm — specified for condensing soft cancellous bone through a minimum osteotomy.
ConnectionOne-piece, compressive thread design
MaterialASTM F136 ELI Grade 5 titanium alloy
SurfaceSurface-treated threads
Also known as i-Fix C-1
02 Indicated for
Indications.
Transcribed from Kamal Medtech's published documentation for this series. Final case selection remains with the treating clinician.
- Narrow ridges needing minimal osteotomy
- Immediate-loading protocols
- Cases aiming to avoid bone augmentation
- Condensation of soft cancellous bone
03 Catalog size matrix
Sizes and Article Codes
27 manufactured combinations, each with its own article code. Rows are diameters, columns are lengths in mm — select a size to order it.
How to order: tap the code of the diameter and length you need, then choose Add to cart. Sizes already in your cart are marked ✓.
| Ø (mm) | 8 | 10 | 12 | 14 | 16 | 18 | 20 |
|---|---|---|---|---|---|---|---|
| Ø 3.5 | |||||||
| Ø 4.0 | |||||||
| Ø 4.5 | — | — | |||||
| Ø 5.0 | — | — | — | ||||
| Ø 5.5 | — | — | — |
Codes and availability transcribed from the current i-Fix Dental Implant Compendium (common catalog). The implant is co-packed with its cover screw.
04 Restorative workflow
Prosthetic components.
One-piece prosthetics. Click any article code to copy it.
05 Design specification
Design features.
Condenses soft cancellous bone
Minimum osteotomy required
Excellent for narrow ridges
Immediate loading
Surface-treated threads
06 Kit & documentation
Kit & documents.
Verify the current catalog, IFU, indications and compatibility before clinical use.
07 Related series
Other implants.
All ASTM F136 ELI Grade 5 titanium alloy, each with its own surgical kit, catalog and IFU.
.webp)
08 Frequently asked
Before you order C Series.
Ø 3.5–5.5 mm across 5 diameter options, in 7 lengths from 8 to 20 mm — 27 manufactured combinations, each with its article code in the catalog size matrix above.
Both are in the Kit & Documentation section above, with the catalog and IFU linked directly.
The Restorative workflow section above lists every family — one-piece prosthetics — with each component's catalog article code.
Yes — linked directly in the Kit & Documentation section above.
Need more detail on the C Series?
Technical, documentation and pricing enquiries reach the manufacturing team directly.
